Dynamic focusing is also known as 3D dynamic marking and it is a new marking scheme which focuses first and then passes through the mirror. The advantage of this scheme is machining curved surfaces (non-plane working surfaces).
See below for the product advantages and a range of customisable variables:
| Serial Number | Working Height （mm） |
Format (mm) |
Design Wavelength （nm） |
Input beam diameter (mm) |
output beam diameter (mm) |
| HY-DTJJ-355-200 | 440 | 200*200 | 355 | 14 | 23 |
| HY-DTJJ-355-400 | 435 | 400*400 | 14 | 23 | |
| HY-DTJJ-355-500 | 540 | 500*500 | 14 | 23 | |
| HY-DTJJ-355-600 | 650 | 600*600 | 14 | 23 | |
| HY-DTJJ-355-700 | 760 | 700*700 | 14 | 23 | |
| HY-DTJJ-1064-500 | 540 | 500*500 | 1064 | 14 | 23 |
| HY-DTJJ-1064-600 | 770 | 600*600 | 14 | 28 | |
| HY-DTJJ-1064-700 | 870 | 700*700 | 14 | 28 |
Spacer
In addition to our current portfolio and custom optical solutions, we also offer a selection of high-performance lenses from our previous product range, available upon request. This includes lenses designed for various markets, applications, and technical specifications.
MORE wavelength options.
MORE depth of focus options.
MORE depth of working distance options.
