QBH Collimator 915nm+980nm

Laser collimators are mainly used in fibre output lasers. According to the fibre interface, it can be divided into QBH and SMA905 and is mainly used to collimate the divergent laser beam.

Product details:

See below for the product advantages and a range of customisable variables:

Advantage Highlights:

  • Imported quartz material
  • High laser-damage threshold coating

Table:

Serial Number Design Wavelength
 (nm)		 Focal Length
(mm)		 Entrance Beam Diameter
 (mm)		 Power
(W)		 Thread Water-cooling or Not
HY-QBH-915-F40-W/WJ 915+980 40 20 4000 M36*0.75/M40*0.75/Four-hole flange Y/N
HY-QBH-915-F50 915+980 50 20 4000 M36*0.75/M40*0.75/Four-hole flange Y/N
HY-QBH-915-F75 915+980 75 20 4000 M36*0.75/M40*0.75/Four-hole flange Y/N
HY-QBH-915-F100 915+980 100 20 4000 M36*0.75/M40*0.75/Four-hole flange Y/N

*Note:

  • In the serial number, "W" stands for water-cooling, and "J" stands for adjustable divergence angle.
  • Connection methods can be selected as either flange or threaded.
  • Supporting for various non-standard focal lengths and connection methods is available for customization.

In addition to our current portfolio and custom optical solutions, we also offer a selection of high-performance lenses from our previous product range, available upon request. This includes lenses designed for various markets, applications, and technical specifications.
MORE wavelength options.
MORE depth of focus options.
MORE depth of working distance options.
